| Nambari ya Sehemu | CLAA098EP01XG |
| Chapa | CPT |
| Ukubwa | 9.8 |
| Maombi | |
| Azimio | 1280×960 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA098EP01XG |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.8 inch |
| azimio | 1280(RGB)×960 , Quad-VGA |
| hali ya kuonyesha | HFFS, Normally Black, Transmissive |
| eneo la kazi | 199.68×149.76 mm |
| uso | |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) + SPI |
