| Nambari ya Sehemu | CLAA101FP0E XG |
| Chapa | CPT |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet Ind |
| Azimio | 1920×1200 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 750:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA101FP0E XG |
| saizi ya paneli | 10.1" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1920(RGB)×1200, WUXGA, 225PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 216.576(W)×135.36(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 229(W)×153(H) ×4.8(D) mm |
| uso | Antiglare |
| mwangaza | 700 cd/m² (Typ.) |
| uwiano wa utofautishaji | 750:1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| hali ya kuonyesha | HFFS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 50% NTSC |
| aina ya taa | WLED , 15K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 150g (Typ.) |
| maombi | Pad & Tablet Industrial Outdoor High Brightness |
| kiolesura cha ishara | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -10 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WA01 | CPT | 10.1 | 1366×768 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
