| Nambari ya Sehemu | CLAA101WA01A |
| Chapa | CPT |
| Ukubwa | 10.1 |
| Maombi | NBPC |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 230 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA101WA01A 3 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 222.72×125.22 mm |
| muhtasari | 235×143×5.2 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Glare (Haze 0%) |
| mwangaza | 230 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193158% |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | NBPC |
| CLAA100XA22XV | CPT | 10.0 | 1024×768 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA102NA01CW | CPT | 10.2 | 1024×600 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| CLAA102NB01XV | CPT | 10.2 | 1024×600 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| B170PW06 V3 | AUO | 17.0 | 1440×900 |
| LQ108M1JW02 | SHARP | 10.8 | 1920×1080 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTN121AT07-L02 | Samsung | 12.1 | 1280×800 |
| LTN154AT08-001 | Samsung | 15.4 | 1280×800 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| N141C1-L01 | Innolux | 14.1 | 1440×900 |
| N156HGE-EA2 | Innolux | 15.6 | 1920×1080 |
