| Nambari ya Sehemu | CLAA123PA02CW |
| Chapa | CPT |
| Ukubwa | 12.3 |
| Maombi | Industrial Outdoor H |
| Azimio | 1440×540 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 700:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | CPT |
| mfano | CLAA123PA02CW |
| ukubwa wa diagonal | 12.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1440(RGB)×540 125PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 291.6(H)×109.35(V) mm |
| muhtasari dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| eneo la bezel | 294.8(H)×112.4(V) mm |
| matibabu | Antiglare (Haze 25%) |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) (TM) |
| tazama mwelekeo | 6 o'clock |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 60/60/50/60 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 16.7M 70% NTSC |
| chanzo cha mwanga | WLED [8S3P] , 30K hours , W/O Driver |
| uzito | 510g (Typ.) |
| iliyoundwa kwa ajili ya | Industrial Outdoor High Brightness Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| CLAA121UA01CW | CPT | 12.1 | 1600×900 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
