| Nambari ya Sehemu | AV123Z7M-N11 |
| Chapa | BOE |
| Ukubwa | 12.3 |
| Maombi | CNS |
| Azimio | 1920×720 |
| Muundo | LCM |
| Mwangaza | 800 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | AV123Z7M-N11 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.3 inch |
| azimio | 1920(RGB)×720 |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| eneo la kazi | 292.032×109.512 mm |
| muhtasari | 307.9×130.27 mm |
| uso | |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 9S4PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 41 pins |
| voltage ya pembejeo | 3.3/6.27/-12/18V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | CNS |
| AT065TN14 | Innolux | 6.5 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LB040Q04-TD01 | LG Display | 4.0 | 320×240 |
| PD040QT2 | E Ink | 4.0 | 320×240 |
| PM065WX3 | E Ink | 6.5 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
