| Nambari ya Sehemu | HSD070IDW1-A00 |
| Chapa | HannStar |
| Ukubwa | 7.0 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 500:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD070IDW1-A00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 153.6×86.64 mm |
| muhtasari | 165×104×5.4 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + FRC) |
| wakati wa majibu | 5/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S7PWLEDWithout Driver |
| kiolesura cha ishara | TTL (1 ch, 6/8-bit), 60 pins |
| voltage ya pembejeo | 3.0/10.0/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | DPF |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| HSD070I651-F20 | HannStar | 7.0 | 480×234 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A20 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-E11 | HannStar | 7.0 | 800×480 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070IFW1-B00 | HannStar | 7.0 | 1024×600 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LB104S02-TD01 | LG Display | 10.4 | 800×600 |
| PM102ZY2 | E Ink | 10.2 | 1024×600 |
