| Nambari ya Sehemu | HSD123JPW3-A10 |
| Chapa | HannStar |
| Ukubwa | 12.3 |
| Maombi | Outdoor High Brightn |
| Azimio | 1920×720 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 11S4P |
| Kiolesura | LVDS |
| mtengenezaji | HannStar |
| jina la mfano | HSD123JPW3-A10 |
| ukubwa wa skrini | 12.3 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1920(RGB)×720 167PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 292.032 × 109.512 (H×V) |
| muhtasari(mm) | 302 × 125.4 × 14.2 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Glare (Haze 0%), Hard coating |
| mwangaza | 850 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1500 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS Pro, Normally Black, Transmissive |
| kina cha rangi | 16.7M 75% NTSC |
| backlight | 11S4P WLED , 30K hours , No Driver |
| wingi | 345/378g (Typ./Max.) |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (2 ch, 8-bit) , Connector 50 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
