| Nambari ya Sehemu | HV208QX1-100 |
| Chapa | HYDIS |
| Ukubwa | 20.8 |
| Maombi | MD |
| Azimio | 2048×1536 |
| Muundo | LCM |
| Mwangaza | 800 |
| CR | 700:1 |
| Rangi | Grayscale |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | BOE HYDIS |
| mfano wa paneli | HV208QX1-100 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 20.8 inch |
| azimio | 2048(LCR)×1536 , QXGA |
| hali ya kuonyesha | AFFS, Normally Black, Transmissive |
| eneo la kazi | 423.9×318 mm |
| muhtasari | 457×350 mm |
| uso | Antiglare (Haze 13%), Hard coating (3H) |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | Grayscale (8-bit) |
| wakati wa majibu | 15/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 12 pcsCCFLEmbedded (Inverter) |
| kiolesura cha ishara | LVDS (4 ch, 8-bit), 70 pins |
| voltage ya pembejeo | 12.0V (Typ.) |
| maombi | MD |
