| Nambari ya Sehemu | R300M1-L01 |
| Chapa | Innolux |
| Ukubwa | 30.0 |
| Maombi | MD |
| Azimio | 4096×2560 |
| Muundo | LCM |
| Mwangaza | 1200 |
| CR | 800:1 |
| Rangi | Grayscale |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | CMO |
| mfano wa paneli | R300M1-L01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 30.0 inch |
| azimio | 4096(LCR)×2560 , DQSXGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 645.12×403.2 mm |
| muhtasari | 678×448×49.5 mm |
| uso | Antiglare (Haze 40%), Hard coating (3H) |
| mwangaza | 1200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Min.) |
| kuonyesha rangi | Grayscale (10-bit) |
| wakati wa majibu | 50/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| masafa | 50Hz |
| aina ya taa | CCFLEmbedded (Inverter) |
| kiolesura cha ishara | LVDS (4 ch, 10-bit), 82 pins |
| voltage ya pembejeo | 12.0V (Typ.) |
| maombi | MD |
| HV208QX1-100 | HYDIS | 20.8 | 2048×1536 |
| ITQX21G | IDTech | 20.8 | 2048×1536 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190E6-L01 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L51 | Innolux | 19.0 | 1280×1024 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
