| Nambari ya Sehemu | HVA37WV1-ME0 |
| Chapa | HYDIS |
| Ukubwa | 3.7 |
| Maombi | MPH |
| Azimio | 480×800 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 800:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | HYDIS |
| mfano wa paneli | HVA37WV1-ME0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.7 inch |
| azimio | 480(RGB)×800 , WVGA |
| hali ya kuonyesha | HFFS, Normally Black, Transmissive |
| eneo la kazi | 48.24×80.4 mm |
| muhtasari | 52.54×89.5×1.9 mm |
| uso | |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + Dithering), CIE193171% |
| wakati wa majibu | 33 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 8S1PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| voltage ya pembejeo | 1.8/3.0V (Typ.)(IOVCC/VCC) |
| maombi | MPH |
