| Nambari ya Sehemu | JJ070IA-18L |
| Chapa | Innolux |
| Ukubwa | 7.0 |
| Maombi | Automotive Display |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S2P |
| Kiolesura | LVDS |
| mtengenezaji | Innolux |
| ukubwa wa skrini | 7.0 inch |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| eneo la bezel(mm) | 155.4 × 94.44 (H×V) |
| mwangaza | 750 cd/m² (Typ.) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M 70% NTSC |
| wingi | 195±9g |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (1 ch, 8-bit) , 50 pins FPC |
| usambazaji wa voltage | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| jina la mfano | JJ070IA-18L |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 162.8 × 104.84 (H×V×D) |
| matibabu | Antiglare |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| majibu | 15/10 (Typ.)(Tr/Td) ms |
| hali ya kazi | IPS, Normally Black, Transmissive |
| backlight | 7S2P WLED , 20K hours , No Driver |
| kutumika kwa | Automotive Display |
| skrini ya kugusa | Without |
| BA070WS1-401 | BOE | 7.0 | 1024×600 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| CLAA070LJ01CW | CPT | 7.0 | 800×480 |
| CLAA070NP01HXG | CPT | 7.0 | 1024×600 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LTA070B2C0F | TOSHIBA | 7.0 | |
| PM070WX9 | E Ink | 7.0 | 800×480 |
| PW070DS1T6 | E Ink | 7.0 | 480×234 |
