| Nambari ya Sehemu | KCG057QV1DL-G770 |
| Chapa | Kyocera |
| Ukubwa | 5.7 |
| Maombi | Industrial |
| Azimio | 320×240 |
| Muundo | CSTN-LCD, LCM |
| Mwangaza | |
| CR | 55:1 |
| Rangi | Color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Parallel |
| chapa | Kyocera |
| mfano | KCG057QV1DL-G770 |
| ukubwa wa diagonal | 5.7 inch |
| aina | CSTN-LCD, LCM |
| muundo wa pixel | 320(RGB)×240 [QVGA] 70PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 115.2(H)×86.4(V) mm |
| muhtasari dim. | 144(H)×104.8(V) ×15.3(D) mm |
| eneo la bezel | 119.4(H)×90.6(V) mm |
| matibabu | Hard coating (2H) |
| mwangaza | - |
| uwiano wa utofautishaji | 55:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 180/170 (Typ.)(Tr/Td) |
| angle ya kutazama | 50/50/20/35 (Typ.)(CR≥2) |
| hali ya uendeshaji | STN, Normally Black, Transmissive |
| rangi ya msaada | Color |
| chanzo cha mwanga | CCFL [1 pcs] |
| uzito | 220g (Typ.) |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 75Hz |
| jopo la kugusa | 4-wire Resistive Touch |
| aina ya kiolesura | Parallel Data (1ch, 8-bit) Connector |
| usambazaji wa nguvu | 3.3/5.0V (Typ.)(VDD) |
| mazingira | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
