| Nambari ya Sehemu | LA070WV7-SL02 |
| Chapa | LG Display |
| Ukubwa | 7.0 |
| Maombi | Outdoor High Brightn |
| Azimio | 800×480 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1100:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S3P |
| Kiolesura | LVDS |
| mtengenezaji | LG Display |
| jina la mfano | LA070WV7-SL02 |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| muhtasari(mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| eneo la bezel(mm) | 158.4 × 94.2 (H×V) |
| matibabu | Antiglare (Haze 25%) |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1100 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 16/14 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 65% NTSC |
| backlight | 6S3P WLED , 30K hours , No Driver |
| wingi | 162/167g (Typ./Max.) |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 8-bit) , FPC 50 pins |
| usambazaji wa voltage | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
