| Nambari ya Sehemu | LA123WF4-SR03 |
| Chapa | LG Display |
| Ukubwa | 12.3 |
| Maombi | Automotive Display |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | RSDS |
| chapa | LG Display |
| mfano | LA123WF4-SR03 |
| ukubwa wa diagonal | 12.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×720 167PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 292.032(H)×109.512(V) mm |
| muhtasari dim. | 310(H)×128(V) ×10.75(D) mm |
| eneo la bezel | 296.03(H)×113.5(V) mm |
| matibabu | Hard coating |
| mwangaza | 600 cd/m² (Min.) |
| uwiano wa utofautishaji | 800:1 (Min.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| angle ya kutazama | 89/89/89/89 (Min.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 77% NTSC |
| chanzo cha mwanga | WLED [11S4P] , 10K hours , W/O Driver |
| uzito | 385/400g (Typ./Max.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | RSDS (2 Channel) , 110 pins FPC |
| usambazaji wa nguvu | 3.3/13.0V (Typ.)(VCC/VDD) |
| mazingira | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
