| Nambari ya Sehemu | TJ123NP01BA |
| Chapa | Innolux |
| Ukubwa | 12.3 |
| Maombi | CNS |
| Azimio | 1280×480 |
| Muundo | LCM |
| Mwangaza | 600 |
| CR | 700:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL/RSDS |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | TJ123NP01BA |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 12.3 inch |
| azimio | 1280(RGB)×480 , DVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 291.84×109.44 mm |
| muhtasari | 333.8×134.6×44.1 mm |
| uso | Antiglare |
| mwangaza | 600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193155% |
| wakati wa majibu | 5/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 stringsWLEDWithout Driver |
| kiolesura cha ishara | TTL/RSDS (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 3.3/6.0/-6.0V (Typ.)(VCC/VDDP/VDDN) |
| maombi | CNS |
