| Nambari ya Sehemu | LH480HX1-SD01 |
| Chapa | LG Display |
| Ukubwa | 4.8 |
| Maombi | MPH |
| Azimio | 480×1024 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 700:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | LG Display |
| mfano wa paneli | LH480HX1-SD01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 4.8 inch |
| azimio | 480(RGB)×1024 |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 51.84×110.592 mm |
| muhtasari | 57.64×121.45 mm |
| uso | |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + Dithering), CIE193168% |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5S2PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| voltage ya pembejeo | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| maombi | MPH |
