| Nambari ya Sehemu | TD025THED2 |
| Chapa | TPO |
| Ukubwa | 2.5 |
| Maombi | MPH |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 350:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | TPO |
| mfano wa paneli | TD025THED2 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 2.5 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 49.92×37.44 mm |
| muhtasari | 56.4×49.12×2.5 mm |
| uso | |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193170% |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| angle ya kutazama | 55/55/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| voltage ya pembejeo | 1.8/2.8V (Typ.)(VDDI/VDD) |
| maombi | MPH |
| HVA32WV1-D00 | HYDIS | 3.2 | 480×800 |
| HVA37WV1-ME0 | HYDIS | 3.7 | 480×800 |
| LD043WV1-SP01 | LG Display | 4.3 | 480×854 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| LM18WGSBZ05 | SHARP | 1.8 | 120×160 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| LTP280QV-E01 | Samsung | 2.8 | 240×320 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM022GDH11 | Tianma | 2.2 | 176×220 |
