| Nambari ya Sehemu | LMS480JC01 |
| Chapa | Samsung |
| Ukubwa | 4.8 |
| Maombi | PND |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 280 |
| CR | 350:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LMS480JC01 1 Compatible model |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 4.8 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, TMR |
| eneo la kazi | 104.45×61.2 mm |
| muhtasari | 112.05×73.26 mm |
| uso | |
| mwangaza | 280 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350 : 1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 28 (Typ.)(Tr+Td) |
| angle ya kutazama | 65/65/55/45 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 75Hz |
| aina ya taa | 5S1P+6S1PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 28 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PND |
