| Nambari ya Sehemu | LPM089A128A |
| Chapa | JDI |
| Ukubwa | 8.9 |
| Maombi | Pad & Tablet |
| Azimio | 1536×2048 |
| Muundo | LTPS TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa | JDI |
| mfano | LPM089A128A |
| ukubwa wa diagonal | 8.9 inch |
| aina | LTPS TFT-LCD, LCM |
| muundo wa pixel | 1536(RGB)×2048 [QXGA] 288PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 135.245(H)×180.326(V) mm |
| muhtasari dim. | 140.85(H)×190.75(V) mm |
| eneo la bezel | - |
| matibabu | Hard coating (3H) |
| mwangaza | 420 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Max.)(Tr+Tf) |
| angle ya kutazama | 80/80/80/80 (Min.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 71% NTSC |
| chanzo cha mwanga | WLED [7S4P] , W/O Driver |
| uzito | 90.26g |
| iliyoundwa kwa ajili ya | Pad & Tablet |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | MIPI (2 ch, 4 data lanes) , 51 pins Connector |
| usambazaji wa nguvu | 1.8/3.8V (Typ.)(IOVDD/AVDD) |
| mazingira | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTM09C362Z | TOSHIBA | 8.9 | 1024×600 |
| N089L6-L03 | Innolux | 8.9 | 1024×600 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
