| Nambari ya Sehemu | LQ035Q7DB02R |
| Chapa | SHARP |
| Ukubwa | 3.5 |
| Maombi | HHP |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 50 |
| CR | 70:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ035Q7DB02R |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transflective |
| eneo la kazi | 53.64×71.52 mm |
| muhtasari | 65×85×4.8 mm |
| uso | Hard coating (3H) |
| mwangaza | 50 cd/m² (Typ.) |
| uwiano wa utofautishaji | 70:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 40/40/40/50 (Typ.)(CR≥2)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| maombi | HHP |
