| Nambari ya Sehemu | LQ084V1DG21E |
| Chapa | SHARP |
| Ukubwa | 8.4 |
| Maombi | IA |
| Azimio | 640×480 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 250:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ084V1DG21E |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.4 inch |
| azimio | 640(RGB)×480 , VGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 170.88×129.6 mm |
| muhtasari | 216×152.4 mm |
| uso | |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 20/40 (Typ.)(Tr/Td) |
| angle ya kutazama | 55/55/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1 pcsCCFL |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 31 pins |
| rohs: | |
| maombi | IA |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LQ084V1DG21 | SHARP | 8.4 | 640×480 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ9D011 | SHARP | 8.4 | 640×480 |
| NL10276BC16-06 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| AA050ME01--T1 | Mitsubishi | 5.0 | 800×480 |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| G150XTN03.1 | AUO | 15.0 | 1024×768 |
| G260J1-L05 | Innolux | 25.5 | 1920×1200 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| KCS6448HSTT-X3 | Kyocera | 10.4 | 640×480 |
| LM32K101 | SHARP | 4.7 | 320×240 |
| LTM08C343S | TOSHIBA | 8.4 | 800×600 |
| LTM10C209AF | TOSHIBA | 10.4 | 640×480 |
| UG-2864ASWIG01 | WiseChip | 2.7 | 128×64 |
