LQ121S1LG44


Chapa
SHARP
Ukubwa
12.1
Maombi
IA
Azimio
800×600
Muundo
LCM
Mwangaza
370
CR
450:1
Rangi
262K
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
515
Vipimo

Nambari ya Sehemu LQ121S1LG44
ChapaSHARP
Ukubwa12.1
MaombiIA
Azimio800×600
MuundoLCM
Mwangaza370
CR450:1
Rangi262K
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliSHARP
mfano wa paneliLQ121S1LG44
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli12.1 inch
azimio800(RGB)×600 , SVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi246×184.5 mm
muhtasari276×209×11 mm
usoAntiglare, Hard coating (3H)
mwangaza370 cd/m² (Typ.)
uwiano wa utofautishaji450:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193150%
wakati wa majibu15/30 (Typ.)(Tr/Td)
angle ya kutazama70/70/50/60 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (1 ch, 6-bit), 20 pins
voltage ya pembejeo3.3/5.0V (Typ.)
maombiIA
