| Nambari ya Sehemu | LQ170K1LW02 |
| Chapa | SHARP |
| Ukubwa | 17.0 |
| Maombi | GM |
| Azimio | 1280×768 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 600:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ170K1LW02 3 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1280(RGB)×768 , WXGA |
| hali ya kuonyesha | P-MVA, Normally Black, Transmissive |
| eneo la kazi | 369.6×221.76 mm |
| muhtasari | 413.8×259×16 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC) |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | GM |
