| Nambari ya Sehemu | LQ170M1LA4B |
| Chapa | SHARP |
| Ukubwa | 17.0 |
| Maombi | NBPC |
| Azimio | 1920×1200 |
| Muundo | LCM |
| Mwangaza | 340 |
| CR | 450:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ170M1LA4B 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1920(RGB)×1200 , WUXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 365.76×228.6 mm |
| muhtasari | 382.2×248×7 mm |
| mtindo wa sura | Wedge (PCBA Bent, Depth ≥5.2mm) |
| uso | Glare (Haze 0%), Hard coating (2H), Antireflection |
| mwangaza | 340 cd/m² (Typ.) |
| uwiano wa utofautishaji | 450:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193172% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 6-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | NBPC |
| BT156GW02 V.0 | Innolux | 15.6 | 1366×768 |
| HSD160PHW1-B00 | HannStar | 16.0 | 1366×768 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SPH3 | LG Display | 15.6 | 1920×1080 |
| LP156WH3-TLA1 | LG Display | 15.6 | 1366×768 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| N141C1-L02 | Innolux | 14.1 | 1440×900 |
| N173FGE-E23 | Innolux | 17.3 | 1600×900 |
