| Nambari ya Sehemu | LS030Y3DX01 |
| Chapa | SHARP |
| Ukubwa | 3.0 |
| Maombi | MPH |
| Azimio | 480×800 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LS030Y3DX01 |
| aina ya paneli | CG-Silicon , LCM |
| saizi ya paneli | 3.0 inch |
| azimio | 480(RGB)×800 , WVGA |
| hali ya kuonyesha | ASV, Normally Black, Transmissive |
| eneo la kazi | 38.88×64.8 mm |
| muhtasari | 45.6×76.4 mm |
| uso | |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193175% |
| wakati wa majibu | 11/24 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1S6PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI, 49 pins |
| voltage ya pembejeo | 2.8/2.8V (Typ.)(VDDIO/VCC) |
| maombi | MPH |
