| Nambari ya Sehemu | LTP700WV-F02 |
| Chapa | Samsung |
| Ukubwa | 7.0 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 300:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTP700WV-F02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800×480(RGB) , WVGA |
| hali ya kuonyesha | TN, Normally White, TMR |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 165×104×5.7 mm |
| uso | |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300 : 1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193158% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | DPF |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| DLC0700JBG-T-6 | Other | 7.0 | 1024×600 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
| LTP700WV-F02 | Samsung | 7.0 | 800×480 |
| LW700AT9003 | Innolux | 7.0 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
