| Nambari ya Sehemu | M090AWA5 R0 |
| Chapa | IVO |
| Ukubwa | 9.0 |
| Maombi | Outdoor High Brightn |
| Azimio | 1280×720 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S4P |
| Kiolesura | |
| mtengenezaji | IVO |
| jina la mfano | M090AWA5 R0 |
| ukubwa wa skrini | 9.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×720 (WXGA) 163PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 198.72 × 111.78 (H×V) |
| muhtasari(mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| eneo la bezel(mm) | 201.72 × 114.78 (H×V) |
| matibabu | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| mwangaza | 880 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 30 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 16.7M 70% NTSC |
| backlight | 7S4P WLED , 15K hours , No Driver |
| wingi | 335g (Max.) |
| kutumika kwa | Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
