| Nambari ya Sehemu | M170EG01 VF |
| Chapa | AUO |
| Ukubwa | 17.0 |
| Maombi | DMPC |
| Azimio | 1280×1024 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | M170EG01 VF 3 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 17.0 inch |
| azimio | 1280(RGB)×1024 , SXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 337.92×270.336 mm |
| muhtasari | 358.5×296.5×15.8 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 3.5/1.5 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
| M170E5-L08 | Innolux | 17.0 | 1280×1024 |
| M170E5-L0A | Innolux | 17.0 | 1280×1024 |
| M170EG01 V7 | AUO | 17.0 | 1280×1024 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EG01 VF | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170EG02 V3 | AUO | 17.0 | 1280×1024 |
| M170EP01 V0 | AUO | 17.0 | 1280×1024 |
| M170ETN01.1 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| LM185WH1-TLF4 | LG Display | 18.5 | 1366×768 |
| LM215WF3-SDA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| M201UN02 V6 | AUO | 20.1 | 1600×1200 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| TM150XG-26L06A | SANYO | 15.0 | 1024×768 |
