| Nambari ya Sehemu | M270DAN01.0 |
| Chapa | AUO |
| Ukubwa | 27.0 |
| Maombi | DMPC |
| Azimio | 2560×1440 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 1000:1 |
| Rangi | 1.07B |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | M270DAN01.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 27.0 inch |
| azimio | 2560(RGB)×1440 , Quad-HD |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 596.736×335.664 mm |
| muhtasari | 630×368.2×11.1 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 1.07B (8-bit + Hi-FRC), sRGB |
| wakati wa majibu | 12 (Typ.)(G to G) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 17S4PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (4 ch, 10-bit), 70 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
