Innolux M236HJJ-P02 Rev.C1 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com
LookLCD LookLCD


M236HJJ-P02 Rev.C1

M236HJJ-P02 Rev.C1
M236HJJ-P02 Rev.C1 thumb
Chapa
Innolux
Ukubwa
23.6
Maombi
Desktop Monitor
Azimio
1920×1080
Muundo
a-Si TFT-LCD, CELL
Mwangaza
CR
3000:1
Rangi
16.7M
Mwangaza nyuma
No
Kiolesura
LVDS
In Stock
12489
Vipimo

Nambari ya Sehemu M236HJJ-P02 Rev.C1
ChapaInnolux
Ukubwa23.6
MaombiDesktop Monitor
Azimio1920×1080
Muundoa-Si TFT-LCD, CELL
Mwangaza
CR3000:1
Rangi16.7M
Mwangaza nyumaNo
KiolesuraLVDS
chapa ya paneliInnolux
mfano wa paneliM236HJJ-P02 Rev.C1
saizi ya paneli23.6"
aina ya panelia-Si TFT-LCD, CELL
azimio1920(RGB)×1080, FHD, 93PPI
muundo wa pixelRGB Vertical Stripe
eneo la maonyesho521.28(W)×293.22(H) mm
ufunguzi wa bezel-
saizi ya muhtasari534.28(W)×306.252(H) mm
usoAntiglare (Haze 3%), Hard coating (3H)
mwangaza0 cd/m²
uwiano wa utofautishaji3000:1 (Typ.) (TM)
angle ya kutazama89/89/89/89 (Typ.)(CR≥10)
hali ya kuonyeshaSuper MVA, Normally Black, Transmissive
mwonekano bora zaidiSymmetry
wakati wa majibu10 (Typ.)(G to G)
kioo kina-
uhamishaji4.6% (Typ.)(with Polarizer)
kuonyesha rangi16.7M   72% NTSC
aina ya taaNo B/L
masafa60Hz
skrini ya kugusaWithout
dereva icCOFBuilt-in 6 source chips
uzito wa paneliTBD
maombiDesktop Monitor
kiolesura cha isharaLVDS (2 ch, 8-bit) , 30 pins Connector
voltage ya pembejeo5.0V (Typ.)
mazingiraOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
