| Nambari ya Sehemu | MV236WHM-N10 |
| Chapa | BOE |
| Ukubwa | 23.6 |
| Maombi | DMPC |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | MV236WHM-N10 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 23.6 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| eneo la kazi | 521.471×293.184 mm |
| muhtasari | 544.8×320.5 mm |
| uso | Antiglare (Haze 1%), Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193174% |
| wakati wa majibu | 14 (Typ.)(G to G) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 14S2PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 12.0V (Typ.) |
| maombi | DMPC |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-P02 | Innolux | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
| HT170E02-100 | BOE | 17.0 | 1280×1024 |
| LM215WF3-SLA2 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM230WF5-TRC2 | LG Display | 23.0 | 1920×1080 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| M190EG02 V4 | AUO | 19.0 | 1280×1024 |
| MT220WW01 V.5 | Innolux | 22.0 | 1680×1050 |
| TX43D14VC0CAB | KOE | 17.0 | 1280×1024 |
