| Nambari ya Sehemu | NL12880BC20-25F |
| Chapa | NLT |
| Ukubwa | 12.1 |
| Maombi | Industrial Outdoor H |
| Azimio | 1280×800 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 3 |
| Kiolesura | LVDS |
| mtengenezaji | NLT |
| jina la mfano | NL12880BC20-25F |
| ukubwa wa skrini | 12.1 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1280(RGB)×800 (WXGA) 124PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 261.12 × 163.2 (H×V) |
| muhtasari(mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| eneo la bezel(mm) | 266.1 × 168.2 (H×V) |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 1600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 15 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | 6 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 262K/16.7M 50% NTSC |
| backlight | 3 strings WLED , 60K hours , No Driver |
| wingi | 470g (Typ.) |
| kutumika kwa | Industrial Outdoor High Brightness |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
