| Nambari ya Sehemu | NL3224BC35-22 |
| Chapa | NLT |
| Ukubwa | 5.5 |
| Maombi | IA |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 750 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | NEC |
| mfano wa paneli | NL3224BC35-22 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 5.5 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 111.36×83.52 mm |
| muhtasari | 134×104.5 mm |
| uso | Clear, Hard coating (2H), Antireflection |
| mwangaza | 750 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 5/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 55/55/50/40 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | CMOS (1 ch, 6-bit), 33 pins |
| voltage ya pembejeo | 3.3/5.0V (Typ.)(VCC) |
| maombi | IA |
