| Nambari ya Sehemu | PW056XU1 |
| Chapa | E Ink |
| Ukubwa | 5.5 |
| Maombi | VDP |
| Azimio | 480×234 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 350:1 |
| Rangi | Full color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | PVI |
| mfano wa paneli | PW056XU1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 5.5 inch |
| azimio | 480(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 121.68×68.45 mm |
| muhtasari | 136×82.6×6.1 mm |
| uso | Antiglare |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | Full color |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | TFT Specific Analog RGB, 30 pins |
| voltage ya pembejeo | 3.3/3.3/5.0/17.0/12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| maombi | VDP |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| H546TAN01.0 | AUO | 5.5 | 720×1280 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| LTA055B0R0A | TOSHIBA | 5.5 | 480×234 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| PW050XS3 | E Ink | 5.0 | 320×220 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| A056DN01 | AUO | 5.6 | 320×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| AT050TN22 V.1 | Innolux | 5.0 | 640×480 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| LB065WQ3-TD02 | LG Display | 6.5 | 400×240 |
| LQ6AN101 | SHARP | 5.6 | 320×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
