| Nambari ya Sehemu | NL8060BC26-11 |
| Chapa | NLT |
| Ukubwa | 10.4 |
| Maombi | IA |
| Azimio | 800×600 |
| Muundo | LCM |
| Mwangaza | 190 |
| CR | 150:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | NEC |
| mfano wa paneli | NL8060BC26-11 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 800(RGB)×600 , SVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 211.2×158.4 mm |
| uso | |
| mwangaza | 190 cd/m² (Typ.) |
| uwiano wa utofautishaji | 150:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193142% |
| wakati wa majibu | 40 (Max.)(Tr) |
| angle ya kutazama | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | CMOS (1 ch, 6-bit), 41 pins |
| voltage ya pembejeo | 3.3/5.0V (Typ.)(VCC) |
| maombi | IA |
| NL8060BC21-11F | NLT | 8.4 | 800×600 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
| NL8060BC26-15 | NLT | 10.4 | 800×600 |
| NL8060BC26-28 | NLT | 10.4 | 800×600 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| AA150XN01 | Mitsubishi | 15.0 | 1024×768 |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| PD057VT3 | E Ink | 5.7 | 640×480 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
| TLX-1741-C3M | TOSHIBA | 5.4 | 240×128 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
