| Nambari ya Sehemu | NL8060BC26-28 |
| Chapa | NLT |
| Ukubwa | 10.4 |
| Maombi | IA |
| Azimio | 800×600 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 700:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | NEC |
| mfano wa paneli | NL8060BC26-28 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 800(RGB)×600 , SVGA |
| hali ya kuonyesha | SA-SFT, Normally Black, Transmissive |
| eneo la kazi | 211.2×158.4 mm |
| muhtasari | 243×185.1 mm |
| uso | Clear, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| wakati wa majibu | 25/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| NL8060AC26-05 | NLT | 10.4 | 800×600 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-11 | NLT | 8.4 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| NL8060BC21-11F | NLT | 8.4 | 800×600 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| NL8060BC31-41E | NLT | 12.1 | 800×600 |
| NL8060BC31-47D | NLT | 12.1 | 800×600 |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| EL320.256-FD7 HB | Lumineq | 4.8 | 320×256 |
| G240HW01 V0 | AUO | 24.0 | 1920×1080 |
| LM8V301 | SHARP | 7.7 | 640×480 |
| LT065AB3D600 | TOSHIBA | 6.5 | |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| SX19V007 | KOE | 7.5 | 640×480 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
