OEL9M0078-Y-E

OEL9M0078-Y-E
OEL9M0078-Y-E thumb
Chapa
Other
Ukubwa
1.45
Maombi
IA
Azimio
132×16
Muundo
OLED
Mwangaza
100
CR
10000:1
Rangi
Mono(Yellow)
Mwangaza nyuma
self
Kiolesura
CPU/SPI/I²C
In Stock
14868
Vipimo

Nambari ya Sehemu OEL9M0078-Y-E
ChapaOther
Ukubwa1.45
MaombiIA
Azimio132×16
MuundoOLED
Mwangaza100
CR10000:1
RangiMono(Yellow)
Mwangaza nyumaself
KiolesuraCPU/SPI/I²C
chapa ya paneliTRULY
mfano wa paneliOEL9M0078-Y-E
aina ya paneli PM-OLED , OLED
saizi ya paneli1.45 inch
azimio132×16
eneo la kazi36.412×4.62 mm
muhtasari43.06×11.75×1.6 mm
uso
mwangaza100 cd/m² (Typ.)
uwiano wa utofautishaji10000 : 1 (Min.)
kuonyesha rangiMono(Yellow) (1-bit)
angle ya kutazama80/80/80/80 (Min.)(CR≥10)(L/R/U/D)
dereva icTAB Built-in SSD1305T7R1
kiolesura cha ishara8-bit 6800/8080 parallel, SPI, I²C, 31 pins
voltage ya pembejeo3.0/11.0V (Typ.)(VDD/VCC)
maombiIA
