| Nambari ya Sehemu | P101DCZ-3Z0 |
| Chapa | Innolux |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet |
| Azimio | 800×1280 |
| Muundo | CELL , a-Si TFT-LC |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | MIPI |
| mtengenezaji | Innolux |
| ukubwa wa skrini | 10.1 inch |
| nambari ya pixel | 800(RGB)×1280 (WXGA) 150PPI |
| eneo amilifu(mm) | 135.36 × 216.576 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 0 cd/m² |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| unene wa kioo | - |
| kina cha rangi | 16.7M 59% NTSC |
| wingi | - |
| kiwango cha upya | 60Hz |
| aina ya ishara | MIPI (4 data lanes) , 40 pins Connector |
| usambazaji wa voltage | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| jina la mfano | P101DCZ-3Z0 |
| aina ya skrini | CELL , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | - |
| matibabu | Clear, Hard coating (3H) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| hali ya kazi | AAS, Normally Black, Transmissive |
| uhamishaji | 4.73% (Typ.)(with Polarizer) |
| backlight | No B/L |
| kutumika kwa | Pad & Tablet |
| skrini ya kugusa | Without |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101N6-L02 | Innolux | 10.1 | 1024×576 |
