| Nambari ya Sehemu | B101UAN02.1 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1920×1200 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B101UAN02.1 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1920(RGB)×1200 , WUXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 216.81×135.5 mm |
| muhtasari | 229.45×149.2×5 mm |
| uso | Glare (Haze 0%), Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193168% |
| wakati wa majibu | 13/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5 stringsWLEDWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 50 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
