| Nambari ya Sehemu | PD040QX1 |
| Chapa | E Ink |
| Ukubwa | 4.0 |
| Maombi | CNS |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 400:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | PVI |
| mfano wa paneli | PD040QX1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 4.0 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 81.12×60.84 mm |
| muhtasari | 93×73.5 mm |
| uso | Antiglare |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 4S2PWLEDWithout Driver |
| kiolesura cha ishara | TTL (1 ch, 8-bit), 60 pins |
| voltage ya pembejeo | 3.3/3.3/9.6/17.0/-8.0V (Typ.)(VCC1/VCC2/VDDA/VCG/VEE) |
| maombi | CNS |
