| Nambari ya Sehemu | PW100XS1 |
| Chapa | E Ink |
| Ukubwa | 10.0 |
| Maombi | CNS |
| Azimio | 640×468 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 350:1 |
| Rangi | Full color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | PVI |
| mfano wa paneli | PW100XS1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.0 inch |
| azimio | 640(RGB)×468 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 216×129.636 mm |
| muhtasari | 235×145.8×6.4 mm |
| uso | Antiglare |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | Full color |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | TFT Specific Analog RGB, 32 pins |
| voltage ya pembejeo | 3.3/3.3/13.0/20.0/-8.0V (VCC/VDD1/VDD2/VGH/VEE) |
| maombi | CNS |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LTA065B626A | TOSHIBA | 6.5 | 400×234 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
