| Nambari ya Sehemu | PW100XS5 |
| Chapa | E Ink |
| Ukubwa | 10.0 |
| Maombi | CNS |
| Azimio | 640×468 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 350:1 |
| Rangi | Full color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | PVI |
| mfano wa paneli | PW100XS5 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.0 inch |
| azimio | 640(RGB)×468 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 216×129.636 mm |
| muhtasari | 235×145.8×6.4 mm |
| uso | Antiglare |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | Full color |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | TFT Specific Analog RGB, 32 pins |
| voltage ya pembejeo | 3.3/5.0/12.5/24.0/-8.0V (Typ.)(VCC/VDD2/VDD1/VGH/VEE) |
| maombi | CNS |
