| Nambari ya Sehemu | S035V04-T |
| Chapa | CDTECH |
| Ukubwa | 3.5 |
| Maombi | Industrial Handheld |
| Azimio | 480×640 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 8S1P |
| Kiolesura | Parallel |
| chapa ya paneli | CDTECH |
| mfano wa paneli | S035V04-T |
| saizi ya paneli | 3.5" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 480(RGB)×640, VGA, 228PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 53.28(W)×71.04(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 64(W)×85(H) ×5(D) mm |
| uso | - |
| mwangaza | 650 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 65/65/55/65 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 9 o'clock |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 50% NTSC |
| aina ya taa | 8S1P WLED , 25K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | 4-wire Resistive Touch |
| uzito wa paneli | TBD |
| maombi | Industrial Handheld & PDA |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) , 39 pins FPC |
| voltage ya pembejeo | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
