| Nambari ya Sehemu | T315XW01 V5 |
| Chapa | AUO |
| Ukubwa | 31.5 |
| Maombi | LCTV |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 1200:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | T315XW01 V5 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 31.5 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | AMVA, Normally Black, Transmissive |
| eneo la kazi | 697.685×392.256 mm |
| muhtasari | 760×450 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1200:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | CCFLEmbedded (Inverter) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | LCTV |
| T315XW02 VD | AUO | 31.5 | 1366×768 |
| T315XW02 VK | AUO | 31.5 | 1366×768 |
| T315XW02 VM | AUO | 31.5 | 1366×768 |
| T315XW03 V4 | AUO | 31.5 | 1366×768 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| T315XW04 V0 | AUO | 31.5 | 1366×768 |
| T315XW04 V3 | AUO | 31.5 | 1366×768 |
| T315XW06 V0 | AUO | 31.5 | 1366×768 |
| T315XW06 V3 | AUO | 31.5 | 1366×768 |
| T315XW06 V5 | AUO | 31.5 | 1366×768 |
| HT201V01-101 | BOE | 20.1 | 640×480 |
| LC370EUN-SDV2 | LG Display | 37 | 1920×1080 |
| LC420DUE-SFR2 | LG Display | 42 | 1920×1080 |
| LC470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| T420HB01 V1 | AUO | 42 | 1920×1080 |
| T420HW07 V1 | AUO | 42 | 1920×1080 |
| T420HW09 V2 | AUO | 42 | 1920×1080 |
| V260B1-L01 | Innolux | 26.0 | 1366×768 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
