| Nambari ya Sehemu | TCG121WXLPAPNN-AN20 |
| Chapa | Kyocera |
| Ukubwa | 12.1 |
| Maombi | IA |
| Azimio | 1280×800 |
| Muundo | LCM |
| Mwangaza | 500 |
| CR | 750:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Kyocera |
| mfano wa paneli | TCG121WXLPAPNN-AN20 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 12.1 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | AWV, Normally Black, Transmissive |
| eneo la kazi | 261.12×163.2 mm |
| muhtasari | 277.7×182.5 mm |
| uso | Antiglare |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 750:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC) |
| wakati wa majibu | 18/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
