| Nambari ya Sehemu | TM028HDZ58 |
| Chapa | TIANMA |
| Ukubwa | 2.8 |
| Maombi | Mobile Phone |
| Azimio | 240×320 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 65K/262K |
| Mwangaza nyuma | 1S4P |
| Kiolesura | Parallel |
| mtengenezaji | TIANMA |
| jina la mfano | TM028HDZ58 |
| ukubwa wa skrini | 2.8 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 240(RGB)×320 (QVGA) 141PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 43.2 × 57.6 (H×V) |
| muhtasari(mm) | - |
| mwangaza | - |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| angle ya kutazama | 60/60/60/50 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | 6 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 65K/262K 55% NTSC |
| backlight | 1S4P WLED , No Driver |
| wingi | - |
| kutumika kwa | Mobile Phone |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) + SPI |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
