| Nambari ya Sehemu | TM028LDH01 |
| Chapa | Tianma |
| Ukubwa | 2.8 |
| Maombi | MPH |
| Azimio | 240×400 |
| Muundo | LCM |
| Mwangaza | 220 |
| CR | 450:1 |
| Rangi | 65K |
| Mwangaza nyuma | WLED |
| Kiolesura | CPU |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM028LDH01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 2.8 inch |
| azimio | 240(RGB)×400 , WQVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 36.72×61.2 mm |
| muhtasari | 42.42×72.8 mm |
| uso | Clear, Hard coating (3H) |
| mwangaza | 220 cd/m² (Typ.) |
| uwiano wa utofautishaji | 450:1 (Typ.) |
| kuonyesha rangi | 65K , CIE193152% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1S4PWLEDWithout Driver |
| kiolesura cha ishara | CPU, 37 pins |
| voltage ya pembejeo | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| maombi | MPH |
