| Nambari ya Sehemu | TM035KDH03 |
| Chapa | Tianma |
| Ukubwa | 3.5 |
| Maombi | DSC |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel/Serial |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM035KDH03 2 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 70.08×52.56 mm |
| muhtasari | 76.9×63.9×3.35 mm |
| uso | Clear, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6S1PWLEDWithout Driver |
| kiolesura cha ishara | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | DSC |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03-36 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH08 | Tianma | 3.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| TM035WBHG01 | Tianma | 3.5 | 480×640 |
| A025DL02 V5 | AUO | 2.5 | 320×240 |
| A027DN01 VB | AUO | 2.7 | 320×240 |
| A027DN03 V5 | AUO | 2.7 | 320×240 |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| LTV250QV-F0A | Samsung | 2.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TD024THEB2 | TPO | 2.4 | 480×240 |
| TD025THEEA | TPO | 2.5 | 640×240 |
