| Nambari ya Sehemu | TM050LDZ00 |
| Chapa | Tianma |
| Ukubwa | 5.0 |
| Maombi | CNS |
| Azimio | 240×400 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 200:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM050LDZ00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 5.0 inch |
| azimio | 240(RGB)×400 , WQVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 65.16×108.6 mm |
| muhtasari | 76.3×123.4×12.9 mm |
| uso | Antiglare |
| mwangaza | 400 cd/m² (Min.) |
| uwiano wa utofautishaji | 200:1 (Min.) |
| kuonyesha rangi | 262K (6-bit), CIE193170% |
| wakati wa majibu | 40 (Max.)(Tr+Td) |
| angle ya kutazama | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1S10PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6/8-bit) + SPI, 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | CNS |
