| Nambari ya Sehemu | TM057KDH01-41 |
| Chapa | TIANMA |
| Ukubwa | 5.7 |
| Maombi | Industrial |
| Azimio | 320×240 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 5S3P |
| Kiolesura | Parallel |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM057KDH01-41 |
| saizi ya paneli | 5.7" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 320(RGB)×240, QVGA, 70PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 115.2(W)×86.4(H) mm |
| ufunguzi wa bezel | 118.2(W)×89.4(H) mm |
| saizi ya muhtasari | 144(W)×104.6(H) ×12.8(D) mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | 12 o'clock |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 50% NTSC |
| aina ya taa | 5S3P WLED , 50K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 160g (Typ.) |
| maombi | Industrial |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| ET0570B0DHU | EDT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| KCS057QV1BR-G21 | Kyocera | 5.7 | 320×240 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057KDH05 | Tianma | 5.7 | 320×240 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
